Grandstream GWN7721 10-Port L2-Lite Managed 2.5Gigabit Network Switch with 8x 2.5G Ethernet Ports and 2x 10G SFP+

The GWN7721 is a 10-port Layer 2 Lite Managed Switch, equipped with 8x 2.5G Ethernet ports and 2x 10Gigabit SFP+ ports, suitable for small-to-medium businesses to build scalable, secure, and smart networks. This device supports complex VLAN traffic segmentation, integrates Port based, DSCP/802.1p QoS priority management modes, and bandwidth control which greatly improving the overall network performance. Supports IGMP Snooping and comprehensive security protection. The GWN7721 is easy to manage through the local web user interface, GWN Manager and the cloud using the Grandstream Device Management System (GDMS). Also supports both desktop and wall-mount installation and is widely applicable in network construction scenarios across industries such as hotels, home offices, and small to medium-sized enterprises.

Key Features & Benefits:

• 8x 2.5Gigabit Ethernet ports and 2x 10Gigabit SFP+ ports
• Supports Loop Detection, Cable Test and Port Mirror to quickly locate network faults
• SNMPv2 remote monitoring, fault diagnosis, configuration management
• STP/RSTP to guarantee fast convergence, ensure network stability and provide link load balance
• Supports convenient and intelligent local Web configuration, GWN Manager, and GDMS Netwoking Management
• DHCP Snooping ensures DHCP packets are only allowed from trusted ports to keep the DHCP environment safe
• Built-in QoS allows for prioritization of network traffic
• 3 Year Warranty

Specifications:

• Model: GWN7721
• Network Protocol: IPv4, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
• 2.5 Gigabit Ethernet Ports: 8
• 10Gigabit SFP+ Ports: 2, supports 1Gbps/2.5Gbps/10Gbps
• Max. No. of Supported modules:
  SM-10G: 2
  MM-10G: 2
  RJ45-10G: 1
• Auxiliary Ports: 1 Reset Pinhole
• Power Supply: External 12VDC/1A
• Forwarding Mode: Store-and-forward
• Total non-blocking throughput: 40Gbps
• Switching Capability: 80Gbps
• Jumbo Frame: 1518/2048/3072/4096/5120/6144/7168/8192/9216
• Forwarding Rate: 59.52Mpps
• Pack Buffer: 8Mb
• MAC: 16K MAC address capacity
• VLAN:
  Supports up to 32 VLANs (out of 4K VLAN IDs)
  Port-based VLAN, 802.1Q VLAN
  DHCP Snooping
• LAG: 5
• Multicast: IGMP Snooping, Report Message Suppression
• QoS:
  Auto prioritization of the incoming port of the packet
  Priority Mapping
  Queue scheduling, including SP, WFQ
  Supports port priority, 802.1P priority, and DSCP priority
  Bandwidth control
  Rate limit
• DHCP: DHCP client
• Maintenance:
  Backup and restore, system reboot , Factory Reset, firmware upgrade, Support MAC address search, SNMP, LLDP
  Monitoring including port statistics, port mirroring cable test, Ping
• Security:
  DHCP Snooping
  Spanning tree
  Loop prevention
  PoE Watchdog
  Kensington Security Slot (Kensington Lock) support
• Casing: Metal
• Mounting: Desktop/Wall-Mount
• LED Indicators:
  Per device: Power - Green
  Per port: Link/Activity - Green
• Environmental:
  Operating Temperature: 0 to 45 °C
  Storage Temperature: -20 to 60 °C
  Operating Humidity: 10% to 90% Non-condensing
  Storage Humidity: 10% to 90% Non-condensing
• Unit Dimensions (LxWxH): 190 x 100 x 28 mm
• Unit Weight: 0.52 kg
• Package Dimensions (LxWxH) : 300 x 130 x 53 mm
• Package Weight: 0.74 kg
• Package Contents:
  1x Switch
  1x Power Adapter
  1x QIG
• Compliance: FCC, CE, RCM, IC

 PartnerNET Grandstream GWN7721(P) L2-Lite Managed 2.5 Gigabit Switches Datasheet
